1.手动液压纱辊经轴搬运车也叫经轴运输车，液压盘头车,车身重型设计，适合长时间工作.
2. 主要运动部位装配有耐磨导向环,小体积液压装置，操作简单，使用方便.
3.手柄设计符合人体工程学原理，具有三大功能：提升、搬运、放下；
4.整体铸造油缸，镀铬活塞杆，内部溢流阀提供过载保护，下降速度控制
5.手动液压纱辊经轴搬运车是搬运纸筒、地毯、布料、电缆、木头、钢卷、轮胎等圆柱形物的搬运好帮手.
6. 整机优质钢板打造，坚固耐用，降低维修费用.
手动液压纱辊经轴搬运车产品参数：
|
型 号 Model |
CBY500-Z |
CBY1000-Z |
CBY1500-Z |
CBY2000-Z |
CBY3000-Z |
|
订 货 号Order Number |
5.09001 |
5.09002 |
5.09003 |
5.09004 |
5.09005 |
|
额定载重 Capacity (kg) |
500 |
1000 |
1500 |
2000 |
3000 |
|
起升高度Fork lift height(mm) |
115 |
115 |
115 |
115 |
115 |
|
货叉最低Fork min height (mm) |
145 |
145 |
145 |
155 |
155 |
|
货叉最高Fork max.height(mm) |
260 |
260 |
260 |
260 |
260 |
|
货叉单宽Fork width (mm) |
180 |
180 |
180 |
180 |
180 |
|
货叉外宽Fork over width(mm) |
1000 |
900 |
800 |
600 |
600 |
|
货叉长度Fork length (mm) |
700 |
900 |
1100 |
1300 |
1500 |
|
车身重量Weight (Kg) |
79 |
85 |
96 |
107 |
139 |
|
外形尺寸Over size(mm)L*W*H |
1100*1000*1370 |
1300*900*1370 |
1500*800*1370 |
1700*600*1370 |
1900*600*1370 |
|
通道要求 Channel request(mm) |
1200转弯Turn |
1400转弯Turn |
1600转弯Turn |
1800转弯Turn |
2000转弯Turn |
|
行走通道Forward and Back request |
1100mm |
1000mm |
900mm |
700mm |
700mm |
|
后轮 Real wheels (mm) |
2*¢180*50 |
||||
|
前轮Front wheels (mm) |
4*¢80*70 |
||||
1.Manual Yarn Roller Pallet Truck also called yarn beam transport vehicle/hydraulic head vehicle.
Heavy body design, suitable for long time work
2.Assemble a wear resistant guide ring, Small volume hydraulic device, operation is simple and easy to use
3.Handle design accord with human body engineering principle, has three major functions: lifting, moving and down.
4.Integrally cast cylinder, chrome plated piston rod, internal relief valve to provide overload protection, speed drop control.
5.Manual Yarn Roller Trolley is a good helper for handling rolls, carpet, cloth, cable,wood, steel and rolls tires…etc.
6.Whole steel manufacturing, Strong and durable, lower maintenance costs
